16A 12VDC SPDT PCB Mount Relay

12V Relay

16A SPDT relay. PCB mount style. 12V DC coil.
Fully sealed construction makes it ideal for immersion cleaning and large scale manufacturing.

• Max Switching Voltage: 250V AC, 110V DC
• Max Switching Current: 16A
• Max VA (Watts): 1800VA (450W)
• Contact Material: Silver Selenium Dioxide
• Coil Resistance: 200Ω
• Max Coil Power: 720mw
• Insulation Resistance: >100MΩ @ 500V DC
• Dielectric Strength (for 1 min):
• 1000V AC between open contacts
• 5000V AC between coil & contact
• Electrical Life: 100,000 operations
• Mechanical Life: 10 million operations
• Dimensions: 13W x 29L x 21H mm

  *Specifications are subject to change without notice
