4-Channel Universal Fast Battery Charger with LCD
Fast Charges up to 4 Li-ion, LiFePo4, Ni-Cad & Ni-Mh
SKU: PS3520
4-Channel Universal Fast Battery Charger with LCD
Fast Charges up to 4 Li-ion, LiFePo4, Ni-Cad & Ni-Mh
This intelligent charger has four independent charging slots to charge any combination of Ni-MH, Ni-Cd, Li-ion, or LiFePO4 cells at the same time. The microprocessor monitors each battery and provides a safe and effective charge using precise Pulse Width Modulation (PWM) technology. A single Li-ion or LiFePO4 cell can also be fast charged at up to 2A. The high contrast LCD screen provides real-time battery monitoring, including charging current (A), charging capacity (mAh), voltage (V) and battery power (%). Features include alarm and error messages for bad batteries, reverse polarity protection, short circuit, over-charge, and over-temperature. Power comes from an available USB port using the supplied USB Type-C power cable.
Features:
• Suits Ni-MH, N-Cd, Li-ion & LiFePO4
• Intelligent fast charging up to 2A
• Independent charging slots
• LCD screen
Supported Batteries:
3.6-3.7V Li-ion
3.2V LifePO4
1.2V Ni-MH/Ni-Cd
Specifications
| Width : 96mm |
| Height : 129mm |
| Depth : 32mm |
| Weight : 170g |
| USB Voltage Input : 5V, 5V |
| USB Input Current : 2A, 2A |
| USB Item Connection : Type C |
| USB Lead included : true |
| Packaged Volume : 0.57l |
| Packaged Weight : 0.22kg |
| Packaged Length : 13.5cm |
| Packaged Width : 12cm |
| Packaged Height : 3.5cm |
| Type of Batteries : Nickel Metal Hydride (Ni-MH)Nickel Cadmium (Ni-Cad)Lithium IonLithium Ferrous Phosphate (LiFePO4) |
| Cell Type(s) Charged : AAAAASub-CC10440, 14500, 16340, 17335, 17500, 17670, 18350, 18650, 22650, 26500, 26650, 14650, 18500, 18700, 20700, 21700, 22700 |
| Number of Cells : 4pc |
| Multi-cell Charging Conditions : Independent Charge Control for Each Battery Slot |
| Charger Output Voltage : 4.2V, 3.65V, 1.48V |
| Charger Output Current : 2A, 1A, 650mA, 500mA |
| Controller Type : PWM |
| Reverse Polarity Protection : true |
3 Month Warranty
| SKU | PS3520 |
| Barcode # | 9351634064557 |
| Brand | Aus Electronics Direct |
| Shipping Weight | 0.1900kg |
| Shipping Width | 0.210m |
| Shipping Height | 0.050m |
| Shipping Length | 0.280m |
| Shipping Cubic | 0.002940000m3 |
| Unit Of Measure | ea |
