4 Wheel Drive Motor Driver Module for Arduino Projects
Use to control a 4WD Arduino platform
SKU: TA0065
$19.75
RRP $34.95
In Stock
4 Wheel Drive Motor Driver Module for Arduino Projects
Use to control a 4WD Arduino platform
This module is suitable for robotics, hobbyist or professional who needs a 4WD platrom with individual motor control.
Specifications:
• Motor Supply Voltage: 5-16VDC
• Logic Voltage: 5VDC
• Driver peak current 1A
• Dimensions: 92(L) x 38(W) x 17(H)mm
Feature:
- Driver chips: L293D dual H-bridge DC motor driver chip
- Diven part of the terminal supply area Vs: +5 V ~ +16 V; such as the need to take power within the board, the supply area Vs: 6V to 16V
- Drive part of the peak current Io: 1A
- Logical part of the operating current range: 0 ~ 36mA
- Control signal input voltage range (IN1 IN2 IN3 IN4IN5 IN6 IN7 IN8):
- Low level:-0.3V VIN 1.5V
- High level: 2.3V Vin Vss
- Enable signal input voltage range (EN1 EN2EN3 EN4):
- Low level: -0.3 Vin 1.5V (control signal is invalid)
- High level: 2.3V Vin Vss (control signal)
- Dimensions: 92*38*17mm
CLICK HERE TO SEE OTHER ARDUINO SENSORS
CLICK HERE TO SEE OTHER ARDUINO MODULES
CLICK HERE TO SEE OTHER ARDUINO PRODUCTS
3 Month Warranty
| SKU | TA0065 |
| Barcode # | 9351634002993 |
| Brand | iduino |
| Shipping Weight | 0.1000kg |
| Shipping Width | 0.130m |
| Shipping Height | 0.040m |
| Shipping Length | 0.100m |
| Shipping Cubic | 0.000520000m3 |
| Unit Of Measure | ea |
8-way motor controller
By: James Brown on 10 September 2019This works perfectly. You may wonder why you need an 8-way controller for a 4WD car, doing this gives you forward/backward on each wheel, by setting the voltage across the motor either + or - by moving each wire high or low. Put the 4 red motor wires into the out1 -> out4 pins and the black motor wires into out5 -> out8. Then take 8 digital outputs from the Arduino/ESP and you can control each wheel forwards and backwards. Probably you only need to control left side and right side forward and back so 4 pins would do fine. Anyway, this does exactly what you're expecting it to and doesn't need any messing around. The independent power toggle switch is handy while you're re-flashing too. Nice :)
