4K HDMI 2.0 Audio Splitter / Extractor with HDR, ARC and EDID

Connect your HDMI device to home theatre via RCA/Toslink

SKU: AA6087


$69.95
RRP $149.00
In Stock

Buy In Bulk & Save!
Buy 4 to 10: Pay $66.45 ea
Buy 11 to 20: Pay $63.12 ea
Buy 21 to 100: Pay $59.97 ea




Calculate Shipping

4K HDMI 2.0 Audio Splitter / Extractor with HDR, ARC and EDID



Connect your HDMI device to home theatre via RCA/Toslink



This HDMI 2.0 Audio Splitter/Extractor allows you to connect your HDMI Devices (PS4, XBOX, Set Top Box, Blu-ray) to older hi-fi receivers, amplifiers and even headphones with fibre optic/toslink and analogue RCA Audio inputs.

The HDMI 18Gbps Audio Extractor could extract audio signals from any HDMI compliant source to digital optical or analog stereo L/R audio outputs. Both input and output HDMI support video resolution up to 4K2K@50/60Hz (YUV444). It supports 10bits HDR (High Dynamic Range) pass through and HDMI high resolution digital audio formats bypass, LPCM 2CH, Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio, audio sampling rate up to 192 kHz. HDCP 2.2 and CEC bypass are supported.



Features:

• HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant

• Video resolutions up to 4K2K @ 50/60Hz (YUV444)

• Extracts HDMI audio to multi-channel optical (SPDIF) or L/R analog audio

• Optical audio supports LPCM 2CH, Dobly Digital 2/5.1CH, DTS 2/5.1CH

• Supports HDMI High Bit Rate(HBR) audio pass through

• Audio sample rates up to 192kHz

• 10bits HDR (High Dynamic Range) pass through

• Supports ARC



Specifications:

HDMI resolution : 4K @ 60Hz /4K @ 30Hz/ 1080P / 1080i / 720p / 576p / 576i / 480P / 480i

Support audio format : DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD

Max bandwidth : 600MHz

Max baud rate : 18Gbps

Input/Output TMDS signal : 0.5~1.5Volts p-p(TTL)

Input/Output DDC signal : 5Volts p-p (TTL)

Input cable distance : ≤10m(1080P)/5M(4K) AWG24 HDMI standard cable

Output cable distance : ≤10m(1080P)/5M(4K) AWG24 HDMI standard cable

Max working current : 700mA

Power : USB DC5V

Operating Temperature range : -0 to +40℃

Storage Temperature range : -20 to +60℃

Operating Humidity range : 5 to 85%RH (No Condensation)

Storage Humidity range : 5 to 95%RH (No Condensation)

Dimension (L x W x H) : 106X60X27.3 (mm)

Weight : 85g

CLICK HERE TO SEE OTHER HDMI AUDIO EXTRACTORS IN OUR RANGE

12 Month Warranty

SKU AA6087
Barcode # 9351634016099
Brand Aus Electronics Direct
Shipping Weight 0.3000kg
Shipping Width 0.130m
Shipping Height 0.060m
Shipping Length 0.170m
Shipping Cubic 0.001326000m3
Unit Of Measure ea
