White 10A GPO Double Power Point Socket with RCD

White Double GPO with built-in RCD

Designed to be a direct replacement for your standard GPO fittings, combining two standard 240AC 10A mains (GPO) outlets with a built-in RCD to provide protection against electrical shock. In the event of a fault with the connected appliance or accident, such as cutting through the mains lead, the unit will provide complete isolation from mains. A test button, status indicator, and reset button allows you to check the RCD, which we recommend should be done each time before use.

Meets Australian and New Zealand safety standards.

Please Note: This item should be installed by a licenced electrician.

Features:

- Electric shock protection

- LED status indicator

- Reset and test buttons

- Line power indicator

Specifications:

CD Classified: Type II

Rated Tripping Current: 30mA

Operating Speed: <40mS Max.

L/Nin-L/Nout: 2KV

Endurance: 2000 Cycles Minute

Contact Break:  Double Pole

Standards: RCD Module-AS NZS 3190, Socket-AS NZS 3112

Minimum Back Box Depth: 35mm

Fixing Screws: M3.0 x 25mm

Cable Capacity: 4x2.5mm2,2x4mm2,1X6mm2

Specifications

AC current rating : 20A

AC Voltage rating : 240V

AC Frequency : 50Hz

IP Rating : 30

Dust/Particle Ingress Protection : 3 - Objects > 2.5mm, Tools, thick wires etc

Liquid/Moisture Ingress Protection : 0 - Not protected

Width : 120mm

Height : 76mm

Depth : 50mm

Weight : 144g

Packaged Volume : 0.67l

Packaged Weight : 0.18kg

Packaged Length : 14.7cm

Packaged Width : 8.1cm

Packaged Height : 5.6cm

Plug or Socket Type : Mains AU/NZ 3 Pin

Device : Socket

Dielectric Withstanding Voltage : 6kV
